Air Compressor Spare Parts Energy Efficient Motor

The HDW1100-24D is a compact oil-free silent piston air compressor featuring a 1.1 kW all-copper motor, a 24L air storage tank, and an exhaust capacity of 150 L/min; it operates at a noise level of ≤55 dB, delivers clean, oil-free output airflow, and is particularly well-suited for applications such as dental clinics, small laboratories, electronic repair shops, and home DIY projects where high requirements are placed on air cleanliness and quiet operation.

Huada twin-screw vacuum pump drives the permanent magnet motor through a high-efficiency synchronous open-loop vector inverter, which drives the twin-screw main engine to rotate. Through the air intake valve, air filter and other components, it can extract air from the vacuum system according to the customer's gas demand, and can change the exhaust speed in real time to achieve a stable vacuum degree.

The Yiluma SV-30+ features a 22 kW permanent magnet variable-frequency compressor with a maximum discharge capacity of 3.45 m³/min (0.7 MPa). Through seamless integration of intelligent frequency conversion technology and a dedicated controller, it delivers stable, clean, and easy-to-manage compressed air for medium-sized factories.

The Huada HDW750-24D is a 0.75 kW (1 HP) oil-free silent direct-drive air compressor purpose-built for fine-detail applications such as art airbrushing, model making, and electronic coating that require steady continuous air supply. Featuring a 100% copper-wire motor, electromagnetic unloading valve, and high-efficiency aluminum radiator, it operates at ≤50 dB with clean oil-free output. The 24 L tank ensures stable pressure delivery—an ideal air supply unit for studios and maker spaces.

The HD-22S is an entry-level single-stage permanent magnet variable-frequency screw compressor from the INNOVATE 2.0 series, delivering a power output of 22 kW and a flow rate of 3.7 m³/min, with a stable air supply at 0.8 MPa. Equipped with an IE5 ultra-efficient permanent magnet motor and a German-engineered main unit, it operates at a noise level as low as 72 ± 3 dB, making it ideal for small-to-medium-scale applications such as manufacturing, food packaging, and textile industries.

Widely used in industrial fields,such as various pneumatic tools,instrument control,printing,paper,petrochemical,electronics,automobile manufacturing,rubber tire manufacturing,woodworking machinery,rice processing,furniture manufacturing,garment processing,nitrogen production,and air separation etc.

The Yiluma SV-20+ features a 15 kW permanent magnet variable-frequency drive as its core component, with an exhaust volume of up to 2.40 m³/min (0.7 MPa), balancing energy efficiency and stability. It is widely suitable for continuous gas application scenarios in small-to-medium manufacturing, textile, and electronic assembly industries.

The Huada HD0302(A) is a 2.2 kW (3 HP) dual-cylinder direct-connect air-cooled piston air compressor featuring a parallel twin-cylinder design where two 42 mm cylinders work in tandem to deliver a generous 0.20 m³/min displacement. Paired with a 30 L air receiver and 0.8 MPa (116 psi) working pressure, it can pressurize the tank from zero to rated pressure in approximately 90 seconds. The direct-coupled drive eliminates belt-slip losses, delivering superior mechanical efficiency over traditional belt-driven units. It is widely used in auto detailing and quick-repair shops for tire inflation, small bodywork pneumatic tool operation, finish carpentry nailer supply, wall spray painting, and other multi-tool simultaneous-operation scenarios.
