Air compressors and air receiver tanks are widely used in industrial production and are closely interrelated. An air compressor compresses air into a high-pressure form, while an air receiver tank is used to store the compressed air. The two are often used in conjunction to boost production efficiency. Air compressors have a wide range of applications, such as in spray painting, pneumatic tools, c...

Impacts of Operating the Air Compressor Without a Filter Key Impacts: 1. Oil contamination in compressed air cannot be separated and filtered out, accumulating in the system pipelines over time to form flammable substances. Meanwhile, oil contamination is prone to vaporization at high temperatures, generating acidic substances that corrode the internal components of the unit and shorten its s...

I. Replacement of the Oil Filter Element 1. Unscrew and discard the oil filter element. 2. Thoroughly clean the filter housing and unclog the pressure difference through-holes at the inlet and outlet. 3. Inspect the performance of the pressure difference transmitter. 4. Apply oil to the new filter element (coat a thin layer of oil on the filter element's sealing ring). 5. ...

1. Insufficient flow: A clogged oil filter will impede the normal circulation of lubricating oil, resulting in a reduced oil supply to the main unit, bearings and heat-dissipating components (e.g., airend). 2. Inadequate cooling: Lubricating oil is the primary medium for dissipating heat generated by compression and friction. Reduced flow means a drastic drop in heat dissipation capacity...

The causes of unit malfunctions are diverse, and a single fault is usually not triggered by a single part or factor. Therefore, fault diagnosis and troubleshooting are often quite difficult. The Fault Diagnosis and Troubleshooting Chart is formulated based on practical applications and extensive tests conducted by manufacturers. This chart lists common faults that may occur to the unit, the g...

1. Insufficient cooling water flow in the cooler (water-cooled models only): Clean the cooler. Inspect the water system for faults, including the water temperature control valve; readjust or clean the valve if necessary. 2. Inadequate air circulation in the cooler: Check the cooler’s installation position to ensure there is no obstruction to air flow. Inspect the cooler and clean it...

Noise control of air compressors is mainly implemented through three approaches: silencers, sound-attenuating tunnels and sound insulation technology. 1.Install silencers The primary noise sources are the air inlet and outlet, where suitable inlet and outlet silencers should be installed. The noise spectrum of air compressor inlets exhibits low-frequency characteristics, so the inlet silencer...

When the piston moves from the top dead center to the bottom dead center of the cylinder, the volume inside the cylinder increases and the pressure drops. When the pressure inside the cylinder falls below the ambient atmospheric pressure, driven by the pressure difference between the inside and outside of the cylinder, the outside air overcomes the tension of the spring to push open the ...
