The Yiluma SV-20 20HP PM VSD screw air compressor offers 2.35 m³/min at 0.8 MPa, engineered with a high-performance NdFeB motor and optimized cooling airflow for stable medium-duty performance. It is built for factories that need consistent air supply with lower energy consumption.
Item NO.:
SV-20Product Origin:
ChinaShipping Port:
XiamenLead Time:
7-15 days
Yiluma SV-20 15 kW / 20 HP PM VSD Screw Air Compressor
The Yiluma SV-20 20HP PM VSD screw air compressor offers 2.35 m³/min at 0.8 MPa, engineered with a high-performance NdFeB motor and optimized cooling airflow for stable medium-duty performance. It is built for factories that need consistent air supply with lower energy consumption.
1. Practical workshop capacity. Get 2.35 m³/min at 8 bar from a 15 kW unit.
2. Efficient PM motor. High-strength NdFeB magnets support a compact, efficient motor design.
3.Flexible air delivery. VSD operation follows fluctuating demand instead of running at one fixed output.
4.Coordinated cooling airflow. Lower air inlets work with the top fan to ventilate the cabinet.
5.Direct power transfer. Coupling drive removes the need for belt tensioning and replacement.
|
Model |
SV-20 |
Discharge Pressure(Mpa) |
0.8 |
|
Air Delivery(m³/min) |
2.35 |
Power(kW) |
15 |
|
Lubricant(L) |
5 |
Drive Method |
Variable frequency starting |
|
Cooling |
Air |
Discharge Temperature(℃) |
≤Ambient temperature±15℃ |
|
Electricity(V/Hz) |
380V/50Hz |
Weight(kg) |
290 |
|
Dimension(mm) |
1100*730*1050 |
Air Outlet Pipe Diameter(inch/mm) |
G3/4'' |
1、Company Advantage
Quanzhou Huade Electric Machinery & Equipment Co., Ltd Fujian PRC (formerly Quanzhou city of Fujian province Huada Machinery Co.,Ltd) is located in West Coast city of Quanzhou.Our company is one of the Air Compressor professional manufacturers with the largest domestic and the equipment is the most advanced currently.And our company is an innovative and high-technology enterprise.We specialized in developing,designing,and producing series of piston and screw air compressors.Our company have obtained the certification ISO9001:2000,Chinese Universal machinery certification,and the quality testing of CCC certification,CE certification,CQC certification,and ETL certification.In 2002,we have cooperated with the air end manufacturer in Germany that are GHH-RAND and ROTORCOMP and AERZEN and COMER to improve production technique.And the production update,quality and global sale is our company market strategy all the time.
2、Workshop & Equipment
We have advanced air compressor production equipment and perfect production line.We practice strict quality control procedures throughout the entire production process from procuring of raw materials,processing of components,assembly of machine,to testing machines' performance.
3、Qualification Certificate
We have passed ISO 9001:2015、ISO 14001:2015、IATF16949:2016 certifications.Most of products have passed CE、RoHS、TUV、3C、CNAS、CQC certifications through authoritative institutions.
4、Global Parter
Our air compressors radiate to the whole world, export to more than 100 countries and regions, and maintain long-term stable cooperative relations.Annual traning is offered to global agents and after-sales engineers,for mastering new product,new technology,new material,new crafts in order to offer most advancing high quality product service.
