The German-technology two-stage compression airend compresses air in two stages, cutting specific energy consumption and lifting overall efficiency well above single-stage units.
Item NO.:
HD-45TProduct Origin:
ChinaShipping Port:
XiamenLead Time:
7-15 days
Huada 2.0 Series HD-45T 45kW Two-Stage PM VFD Screw Compressor
The German-technology two-stage compression airend compresses air in two stages, cutting specific energy consumption and lifting overall efficiency well above single-stage units.
1. Two-stage compression airend for higher efficiency
The German-technology two-stage compression airend compresses air in two stages, cutting specific energy consumption and lifting overall efficiency well above single-stage units.
2. Oil-cooled IE4 permanent magnet VFD motor
An oil-cooled IE4 permanent-magnet synchronous motor paired with wide-range VFD matches output to demand, saving energy during partial-load operation.
3. 7-inch smart touchscreen with IoT remote monitoring
A 7-inch color touchscreen and built-in IoT system let you monitor runtime, temperature and faults remotely for proactive maintenance.
4. Compact, low-noise design for easy siting
A space-saving footprint with double-layer sound insulation keeps noise low, making it easy to install close to the production line.
5. Fast energy payback for SMEs
High first-class efficiency and part-load savings shorten the payback period, lowering the total cost of ownership for small and medium enterprises.
Model
HD-45T
Discharge Pressure(Mpa)
0.8
Air Delivery(m³/min)
9.7
Power(kW)
45
Lubricant(L)
40
Driving Way
Direct drive
Cooling
Air Cooling
Discharge Temperature(℃)
Ambient temperature ±15℃
Electricity(V/Hz)
380V/50Hz
Weight(kg)
2050
Dimension(mm)
2050*1550*2050
Air Outlet Pipe Diameter(inch/mm)
G2 "
1、Company Advantage
Quanzhou Huade Electric Machinery & Equipment Co., Ltd Fujian PRC (formerly Quanzhou city of Fujian province Huada Machinery Co.,Ltd) is located in West Coast city of Quanzhou.Our company is one of the Air Compressor professional manufacturers with the largest domestic and the equipment is the most advanced currently.And our company is an innovative and high-technology enterprise.We specialized in developing,designing,and producing series of piston and screw air compressors.Our company have obtained the certification ISO9001:2000,Chinese Universal machinery certification,and the quality testing of CCC certification,CE certification,CQC certification,and ETL certification.In 2002,we have cooperated with the air end manufacturer in Germany that are GHH-RAND and ROTORCOMP and AERZEN and COMER to improve production technique.And the production update,quality and global sale is our company market strategy all the time.
2、Workshop & Equipment
We have advanced air compressor production equipment and perfect production line.We practice strict quality control procedures throughout the entire production process from procuring of raw materials,processing of components,assembly of machine,to testing machines' performance.
3、Qualification Certificate
We have passed ISO 9001:2015、ISO 14001:2015、IATF16949:2016 certifications.Most of products have passed CE、RoHS、TUV、3C、CNAS、CQC certifications through authoritative institutions.
4、Global Parter
Our air compressors radiate to the whole world, export to more than 100 countries and regions, and maintain long-term stable cooperative relations.Annual traning is offered to global agents and after-sales engineers,for mastering new product,new technology,new material,new crafts in order to offer most advancing high quality product service.
