HD two-stage permanent magnet variable frequency screw compressor

/Huada 2.0 Series HD-160T 160kW Two-Stage PM VFD Screw Compressor

Huada 2.0 Series HD-160T 160kW Two-Stage PM VFD Screw Compressor

The flagship Huada 2.0 Series HD-160T outputs 33.6 m3/min at 0.8 MPa, a 160 kW two-stage PM VFD compressor with ultra-long-life rotors for the heaviest industrial duty.

  • Item NO.:

    HD-160T
  • Product Origin:

    China
  • Shipping Port:

    Xiamen
  • Lead Time:

    7-15 days
Share To :
  • Product Details

Huada 2.0 Series HD-160T 160kW Two-Stage PM VFD Screw Compressor

The flagship Huada 2.0 Series HD-160T outputs 33.6 m3/min at 0.8 MPa, a 160 kW two-stage PM VFD compressor with ultra-long-life rotors for the heaviest industrial duty.

1. Ultra-long-life two-stage compression rotor

A new-generation two-stage rotor with premium coating delivers ultra-long service life and sustained peak efficiency.

2. Oil-cooled IE4 PM VFD motor, direct drive

The oil-cooled IE4 PM motor coupled to direct drive removes belt losses, maximizing transmitted power and reliability.

3. Advanced IoT and smart control

A 7-inch smart HMI with IoT gives full visibility and remote control across the air-compressor room.

4. Maximum output for heavy industry

Class-leading 33.6 m3/min flow supports steel, power and large manufacturing plants with demanding peak loads.


Model
HD-160T Discharge Pressure(Mpa)
0.8
Air Delivery(m³/min)
33.6 Power(kW)
160
Lubricant(L)
90 Driving Way
Direct drive
Cooling
Air Cooling
Discharge Temperature(℃)
Ambient temperature ±15℃
Electricity(V/Hz)
380V/50Hz
Weight(kg)
4230
Dimension(mm)
2720*2200*2000 Air Outlet Pipe Diameter(inch/mm)
DN80

1、Company Advantage

Quanzhou Huade Electric Machinery & Equipment Co., Ltd Fujian PRC (formerly Quanzhou city of Fujian province Huada Machinery Co.,Ltd) is located in West Coast city of Quanzhou.Our company is one of the Air Compressor professional manufacturers with the largest domestic and the equipment is the most advanced currently.And our company is an innovative and high-technology enterprise.We specialized  in developing,designing,and producing series of piston and screw air compressors.Our company have obtained the certification ISO9001:2000,Chinese Universal machinery certification,and the quality  testing of CCC certification,CE certification,CQC certification,and ETL certification.In 2002,we have cooperated with the air end manufacturer in Germany that are GHH-RAND and ROTORCOMP and AERZEN and COMER to improve production technique.And the production update,quality and global sale is our company market strategy all the time.


2、Workshop & Equipment

We have advanced air compressor production equipment and perfect production line.We practice strict quality control procedures throughout the entire production process from procuring of raw materials,processing of components,assembly of machine,to testing machines' performance.

3、Qualification Certificate

We have passed ISO 9001:2015、ISO 14001:2015、IATF16949:2016 certifications.Most of products have passed CE、RoHS、TUV、3C、CNAS、CQC certifications through authoritative institutions.

4、Global Parter

Our air compressors radiate to the whole world, export to more than 100 countries and regions, and maintain long-term stable cooperative relations.Annual traning is offered to global agents and after-sales engineers,for mastering new product,new technology,new material,new crafts in order to offer most advancing high quality product service.
