The Huada 2.0 Series HD-90T delivers 19.8 m3/min at 0.8 MPa, a robust 90 kW two-stage PM VFD compressor engineered for continuous mid-duty industrial production.
Item NO.:
HD90-TProduct Origin:
ChinaShipping Port:
XiamenLead Time:
7-15 days
Huada 2.0 Series HD-90T 90kW Two-Stage PM VFD Screw Compressor
The Huada 2.0 Series HD-90T delivers 19.8 m3/min at 0.8 MPa, a robust 90 kW two-stage PM VFD compressor engineered for continuous mid-duty industrial production.
Two-stage compression with intercooling reduces discharge temperature and power draw, raising isothermal efficiency.
2. IE4 oil-cooled permanent magnet VFD motor
The IE4 oil-cooled PM motor stays efficient across the speed range and tolerates harsh, dusty plant environments.
3. Smart touchscreen plus IoT monitoring
A 7-inch HMI and IoT module enable remote start/stop, alarm push and preventive maintenance scheduling.
4. Stable supply for mid-duty lines
Consistent pressure and flow keep pneumatic tools and processes steady, protecting product quality on busy lines.
5. Easy maintenance, low total cost
Front-mounted service points and genuine consumables simplify upkeep and keep the total cost of ownership low.
|
Model |
HD-90T |
Discharge Pressure(Mpa) |
0.8 |
|
Air Delivery(m³/min) |
19.8 |
Power(kW) |
90 |
|
Lubricant(L) |
54 |
Driving Way |
Direct drive |
|
Cooling |
Air Cooling |
Discharge Temperature(℃) |
Ambient temperature ±15℃ |
|
Electricity(V/Hz) |
380V/50Hz |
Weight(kg) |
2750 |
|
Dimension(mm) |
2650*1850*1950 |
Air Outlet Pipe Diameter(inch/mm) |
DN65 |
1、Company Advantage
Quanzhou Huade Electric Machinery & Equipment Co., Ltd Fujian PRC (formerly Quanzhou city of Fujian province Huada Machinery Co.,Ltd) is located in West Coast city of Quanzhou.Our company is one of the Air Compressor professional manufacturers with the largest domestic and the equipment is the most advanced currently.And our company is an innovative and high-technology enterprise.We specialized in developing,designing,and producing series of piston and screw air compressors.Our company have obtained the certification ISO9001:2000,Chinese Universal machinery certification,and the quality testing of CCC certification,CE certification,CQC certification,and ETL certification.In 2002,we have cooperated with the air end manufacturer in Germany that are GHH-RAND and ROTORCOMP and AERZEN and COMER to improve production technique.And the production update,quality and global sale is our company market strategy all the time.
2、Workshop & Equipment
We have advanced air compressor production equipment and perfect production line.We practice strict quality control procedures throughout the entire production process from procuring of raw materials,processing of components,assembly of machine,to testing machines' performance.
3、Qualification Certificate
We have passed ISO 9001:2015、ISO 14001:2015、IATF16949:2016 certifications.Most of products have passed CE、RoHS、TUV、3C、CNAS、CQC certifications through authoritative institutions.
4、Global Parter
Our air compressors radiate to the whole world, export to more than 100 countries and regions, and maintain long-term stable cooperative relations.Annual traning is offered to global agents and after-sales engineers,for mastering new product,new technology,new material,new crafts in order to offer most advancing high quality product service.
