The Huada 2.0 Series HD-132T provides 28.0 m3/min at 0.8 MPa, a heavy-duty 132 kW two-stage PM VFD compressor for large-scale and multi-machine centralized air stations.
Item NO.:
HD-132TProduct Origin:
ChinaShipping Port:
XiamenLead Time:
7-15 days
Huada 2.0 Series HD-132T 132kW Two-Stage PM VFD Screw Compressor
The Huada 2.0 Series HD-132T provides 28.0 m3/min at 0.8 MPa, a heavy-duty 132 kW two-stage PM VFD compressor for large-scale and multi-machine centralized air stations.
1. Heavy-duty two-stage airend
A large two-stage airend with German rotor technology sustains high flow and pressure for demanding, round-the-clock operation.
2. Oil-cooled IE4 PM motor with wide VFD range
The oil-cooled IE4 PM motor with broad frequency range holds efficiency even at low load, cutting idle energy waste.
3. Centralized IoT fleet management
The IoT platform aggregates multiple units, giving plant managers one dashboard for energy, alarms and remote control.
4. Reliable continuous supply for big plants
Redundant cooling and robust direct drive keep supply stable for textile, chemical and automotive lines.
5. Remote O&M cuts downtime cost
Remote diagnostics and predictive alerts shrink unplanned downtime and service travel, lowering operating cost.
|
Model |
HD-132T |
Discharge Pressure(Mpa) |
0.8 |
|
Air Delivery(m³/min) |
28.0 |
Power(kW) |
132 |
|
Lubricant(L) |
90 |
Driving Way |
Direct drive |
|
Cooling |
Air Cooling |
Discharge Temperature(℃) |
Ambient temperature ±15℃ |
|
Electricity(V/Hz) |
380V/50Hz |
Weight(kg) |
3680 |
|
Dimension(mm) |
2720*2200*2000 |
Air Outlet Pipe Diameter(inch/mm) |
DN80 |
1、Company Advantage
Quanzhou Huade Electric Machinery & Equipment Co., Ltd Fujian PRC (formerly Quanzhou city of Fujian province Huada Machinery Co.,Ltd) is located in West Coast city of Quanzhou.Our company is one of the Air Compressor professional manufacturers with the largest domestic and the equipment is the most advanced currently.And our company is an innovative and high-technology enterprise.We specialized in developing,designing,and producing series of piston and screw air compressors.Our company have obtained the certification ISO9001:2000,Chinese Universal machinery certification,and the quality testing of CCC certification,CE certification,CQC certification,and ETL certification.In 2002,we have cooperated with the air end manufacturer in Germany that are GHH-RAND and ROTORCOMP and AERZEN and COMER to improve production technique.And the production update,quality and global sale is our company market strategy all the time.
2、Workshop & Equipment
We have advanced air compressor production equipment and perfect production line.We practice strict quality control procedures throughout the entire production process from procuring of raw materials,processing of components,assembly of machine,to testing machines' performance.
3、Qualification Certificate
We have passed ISO 9001:2015、ISO 14001:2015、IATF16949:2016 certifications.Most of products have passed CE、RoHS、TUV、3C、CNAS、CQC certifications through authoritative institutions.
4、Global Parter
Our air compressors radiate to the whole world, export to more than 100 countries and regions, and maintain long-term stable cooperative relations.Annual traning is offered to global agents and after-sales engineers,for mastering new product,new technology,new material,new crafts in order to offer most advancing high quality product service.
