Item NO.:
LGGPM-175Product Origin:
ChinaShipping Port:
XiamenLead Time:
7-15 days
HUADA New A Series LGGPM-175 132 kW Two-Stage PM VSD Screw Air Compressor
The 132 kW HUADA New A LGGPM-175 is rated at 28.0 m³/min at 0.8 MPa. Its two-stage PM VSD design is positioned for substantial plant air demand and flexible production schedules.
1. Airflow at working pressure. LGGPM-175 supplies 28.0 m³/min at 0.8 MPa for a multi-shift manufacturing site.
2. Two-stage airend. LGGPM-175 splits compression into two steps, a design that supports efficient air delivery at the specified pressure.
3. Air on demand. Permanent-magnet VSD control adjusts the 132 kW drive to changing consumption instead of holding one fixed speed.
4. Air-cooling design. LGGPM-175 combines a high-airflow cooling path with fan control to support stable heat removal during operation.
5. Operating visibility. A touchscreen controller lets operators check the running status of LGGPM-175 and adjust settings more easily.
|
Model |
LGGPM-175 |
Discharge Pressure(Mpa) |
0.8 |
|
Air Delivery(m³/min) |
28.0 |
Power(kW) |
132 |
|
Lubricant(L) |
90 |
Driving Way |
Direct Drive |
|
Cooling |
Air Cooling |
Discharge Temperature(℃) |
Ambient temperature ±15℃ |
|
Electricity(V/Hz) |
380V/50Hz |
Weight(kg) |
3050 |
|
Dimension(mm) |
2430*1980*2095 |
Air Outlet Pipe Diameter(inch/mm) |
DN80 |
1、Company Advantage
Quanzhou Huade Electric Machinery & Equipment Co., Ltd Fujian PRC (formerly Quanzhou city of Fujian province Huada Machinery Co.,Ltd) is located in West Coast city of Quanzhou.Our company is one of the Air Compressor professional manufacturers with the largest domestic and the equipment is the most advanced currently.And our company is an innovative and high-technology enterprise.We specialized in developing,designing,and producing series of piston and screw air compressors.Our company have obtained the certification ISO9001:2000,Chinese Universal machinery certification,and the quality testing of CCC certification,CE certification,CQC certification,and ETL certification.In 2002,we have cooperated with the air end manufacturer in Germany that are GHH-RAND and ROTORCOMP and AERZEN and COMER to improve production technique.And the production update,quality and global sale is our company market strategy all the time.
2、Workshop & Equipment
We have advanced air compressor production equipment and perfect production line.We practice strict quality control procedures throughout the entire production process from procuring of raw materials,processing of components,assembly of machine,to testing machines' performance.
3、Qualification Certificate
We have passed ISO 9001:2015、ISO 14001:2015、IATF16949:2016 certifications.Most of products have passed CE、RoHS、TUV、3C、CNAS、CQC certifications through authoritative institutions.
4、Global Parter
Our air compressors radiate to the whole world, export to more than 100 countries and regions, and maintain long-term stable cooperative relations.Annual traning is offered to global agents and after-sales engineers,for mastering new product,new technology,new material,new crafts in order to offer most advancing high quality product service.
Leave A Message
Two Stage Permanent Magnet Screw Air Compressor
Two stage compression screw air compressor reduces the compression ratio per level,reducing internal leakage and increase the volumetric efficiency,reduces the bearing load,improve the working life of the host.Two stage compression instead of single stage compression,nearly a 15% increase in displacement,can realize a 15% more energy saving effect.
75kw Two Stage Large Industrial Rotary Screw Air Compressor
75kw two-stage screw air compressor incorporates Huada's nearly 30 years of screw compressor research and development and production technology,centered on the world's highest level of displacement,and surpasses the global market demand.It is the highest performance and highest quality air compressor.
Two-stage Dry Oil-free Screw Air Compressor
Huada two-stage dry oil-free screw air compressor uses dry oil-free compression to truly achieve 100% oil-free air.The rotor is made of high-quality corrosion-resistant stainless steel materials,high temperature resistance,corrosion resistance,oxidation resistance,and long life.
175HP Two Stage PM Screw Air Compressor
Dobule stage compression structure, more energy saving. The core is the two-level compression of the injection screw air compressor in same power than single-stage compression of the injection screw air compressor and more 12%-23% air volume.
HUADA New A Series LGGPM-50 37 kW Two-Stage PM VSD Screw Air Compressor
The 37 kW HUADA New A LGGPM-50 is rated at 7.1 m³/min at 0.8 MPa. Its two-stage PM VSD design targets reliable, load-matched air supply for medium-sized production areas.
HUADA New A Series LGGPM-30 22 kW Two-Stage PM VSD Screw Air Compressor
The HUADA New A LGGPM-30 combines 22 kW of permanent-magnet variable-speed power with two-stage compression. Its rated delivery is 4.1 m³/min at 0.8 MPa for compact industrial air systems.
HUADA New A Series LGGPM-60 45 kW Two-Stage PM VSD Screw Air Compressor
The HUADA New A LGGPM-60 provides 9.7 m³/min at 0.8 MPa from a 45 kW two-stage PM VSD platform. It is suited to production lines that need a defined flow rating and flexible output control.
HUADA New A Series LGGPM-75 55 kW Two-Stage PM VSD Screw Air Compressor
The 55 kW HUADA New A LGGPM-75 supplies 12.5 m³/min at 0.8 MPa. Its direct-drive, two-stage PM VSD layout provides a focused choice for expanding industrial air demand.
