HD-37S Single-stage Permanent Magnet Variable Frequency Screw Air Compressor (37 kW / 6.4 m³/min)

HD-37S Single-stage Permanent Magnet Variable Frequency Screw Air Compressor (37 kW / 6.4 m³/min)

The HD-37S utilizes Huada's 2.0 Series Single-Stage Permanent Magnet Variable Frequency Drive technology, delivering a discharge capacity of 6.4 m³/min at a power output of 37 kW and a pressure of 0.8 MPa. The German-engineered main unit is paired with an IE5 permanent magnet motor, providing stable and energy-efficient compressed air for mass production lines operating at medium-scale air consumption levels – particularly in machining, electronics, and plastics manufacturing applications.

1. 37 kW – High power output; 6.4 m³/min – Stable gas supply: Rated discharge capacity of 6.4 m³/min at 0.8 MPa – Ideal for small to medium-sized factories with multiple equipment operating simultaneously, ensuring minimal pressure fluctuations and continuous gas supply.

2. IE5 Permanent Magnet Variable Frequency Drive – On-Demand Output: The variable frequency system adjusts rotational speed in real time based on pipeline network pressure, featuring low unloading losses and superior overall energy efficiency compared to conventional industrial-frequency screw compressors.

3. German-engineered main unit + high-efficiency radiator: A large rotor, low-speed main unit paired with a large-area plate-type radiator ensures stable exhaust temperatures (≤ ambient temperature + 15°C), guaranteeing reliable operation in high-temperature workshops.

4. 99.99% air filtration – ensures a cleaner air supply: 3 μm high-precision intake filtration combined with multi-stage oil and gas separation achieves a filtration efficiency of 99.99%, effectively protecting downstream air-using equipment and processes.

5. Five-year warranty on the entire device – worry-free after-sales service: A five-year warranty commitment for core components, complemented by a 24/7 nationwide service hotline and a professional after-sales team, helping to mitigate operational and maintenance risks throughout the user's entire lifecycle.

1、Company Advantage

Quanzhou Huade Electric Machinery & Equipment Co., Ltd Fujian PRC (formerly Quanzhou city of Fujian province Huada Machinery Co.,Ltd) is located in West Coast city of Quanzhou.Our company is one of the Air Compressor professional manufacturers with the largest domestic and the equipment is the most advanced currently.And our company is an innovative and high-technology enterprise.We specialized  in developing,designing,and producing series of piston and screw air compressors.Our company have obtained the certification ISO9001:2000,Chinese Universal machinery certification,and the quality  testing of CCC certification,CE certification,CQC certification,and ETL certification.In 2002,we have cooperated with the air end manufacturer in Germany that are GHH-RAND and ROTORCOMP and AERZEN and COMER to improve production technique.And the production update,quality and global sale is our company market strategy all the time.

2、Workshop & Equipment

We have advanced air compressor production equipment and perfect production line.We practice strict quality control procedures throughout the entire production process from procuring of raw materials,processing of components,assembly of machine,to testing machines' performance.

3、Qualification Certificate

We have passed ISO 9001:2015、ISO 14001:2015、IATF16949:2016 certifications.Most of products have passed CE、RoHS、TUV、3C、CNAS、CQC certifications through authoritative institutions.

4、Global Parter

Our air compressors radiate to the whole world, export to more than 100 countries and regions, and maintain long-term stable cooperative relations.Annual traning is offered to global agents and after-sales engineers,for mastering new product,new technology,new material,new crafts in order to offer most advancing high quality product service.
